STANDOVER HEIGHT |
54CM |
FRAME |
HAND BRUSHED AL6061, FORGED SLIDING DROP OUTS |
FORK |
HAND BRUSHED AL6061, FORGED DROP OUTS |
STEERER |
TUBE AL6061 |
CRANKS |
SAMOX 127MM DIRECT MOUNT, NARROW Q FACTOR
|
PEDALS |
ER CNC'D AL6061, PLATFORM, STUDDED, CARTRIDGE BEARING |
BOTTOM BRACKET |
SAMOX 24MM EXTERNAL CUP |
RIMS |
20 X 28H, DOUBLE WALLED TUBELESS COMPATIBLE |
REAR HUB |
FOUR-BEARING CASSETTE FREEHUB, CNC'D AL6061 |
FRONT HUB |
CNC’D 6 BOLT DISC, AL6061, QR SKEWER |
AXLES |
AL6061 |
CHAIN |
BOX 4 P8 CHAIN |
CHAINRING
|
DIRECT MOUNT, NARROW WIDE 30T, STEEL |
WEIGHT |
8.7KGS W/O PEDALS |
REAR CASSETTE |
BOX 4 P8 11-42T |
BRAKES |
PROMAX DSK926 HYDRAULIC DISC, 160 ROTORS |
LEVERS |
PROMAX BL81 |
FRONT TYRE |
VEE CROWN GEM 20x2.25", 27TPI WB |
REAR TYRE |
VEE CROWN GEM 20x2.25", 27TPI WB |
HEADSET |
1 1/8” CARTRIDGE BEARING, CONVENTIONAL |
STEM |
RITCHEY OS FORGED AL6061, 35MM REACH |
BARS |
560MM RITCHEY OS DOUBLE BUTTED AL6061, 18MM RISE |
GRIPS |
ER LOCK ON KRATON 92MM |
SEAT POST |
RITCHEY QR, 31.8MM
|
SADDLE |
ER WINGED, RAILED |
SEAT CLAMP |
ER BOLT, 28.6MM |
DERAILLEUR |
BOX 4 REAR P8 CLUTCH EQUIPPED MECH |
